Description
KEY PERFORMANCE PROPERTIES
- Protects most typical fire-stop penetration applications up to 4 hours
- Class 2 surface spread of flame classifi¬cations
- Meets Green building requirements
- Easy to work with and fast cleanup
- Can be re-penetrated when laying new cables, ducts, pipes etc
- Good unprimed adhesion to most common construction substrates
- Can be painted
- Resistance to Ozone, UV radiation and temperature extremes
FIRE RATINGS:
ASMACO INTUMESCENT ACRYLIC SEALANT has been tested for the fire rating and found to resist penetration for 4 hours without failure at specified joint configurations. The fire rating achieved as per BS 476 Part 22: 1987 AMD 2014 and are specific to the conditions of testing.
STANDARD COMPLIES:
ASMACO INTUMESCENT ACRYLIC SEALANT has been tested in
- Non-load bearing concrete, block walls, BS EN 1364-1
- Non load bearing elements curtain wall full configurations, BS EN 1364-3
- Non load bearing elements curtain wall part configurations, BS EN 1364-4
- Door shutter & open able windows, BS EN 1634-1
- Building material & structures, BS 476 – 20
- Building material & structures, BS 476 – 22, ISO 834-1, ISO 834-8,
- Doors & shutters ISO 3008
- Building Construction Glazed elements, ISO 3009
- Waterproo¬fing membrane, ASTM D 570, European Union of Agreement UEA tc M.O.AT 30 & 31 para-E, EN 12311-1
- Fire Rated, BS 476 Part 22: 1987 AMD 2014 for 4 hours without any failure.
- To achieve class 2, BS 476 Part 7: 1997.
- Adhesives and Sealants Dubai Municipality Green Building requirements, Passes the test. GBRS Clause 404.02
- UAE Civil Defence Approved.
- Linear expansion joint confi¬gurations according to EN1366-4 and to BS 476 Part 22/1987.
- Pipes and cables penetration systems according to BS 476 Part 22/1987.
STORAGE AND SHELF LIFE:
12 months from date of production if stored in undamaged original sealed containers, in dry conditions and protected from direct sunlight at temperatures below 25oC , don’t allow to freeze.
